EzeeGrind Neo

EzeeGrind Neo

EzeeGrind Neo

ADDING VALUE TO YOUR CNC OFFERINGS

Technical Specifications

Description Unit Specifications
Machine Capacity
No. of CNC axes 5
Tool diameter range for manufacturing mm 3 to 16
Max. work piece diameter for resharpening mm 180
Max. work piece length from GPL for face grinding mm 310
Max. work piece length from GPL for periphery (OD) grinding mm 300
Max. work piece length from GPL for flute grinding – Helix angle 30° mm 310
Linear Axes
Stroke X | Y | Z mm 260 | 260 | 280
Rapid traverse X | Y | Z mm 20 | 20 | 20
A-Axis (Work head)
A Axis Rotation deg infinite
Rotational Speed RPM 800
Spindle taper ISO 50
B-Axis (Work head swivel axis)
Swivel Angle deg +30° / -180°
Rotational Speed RPM 25
Wheel Spindle
No. of grinding spindle ends 1
Spindle power (Coninuous | Peak) kW 7 | 11
Max. spindle speed RPM 9000
Other Data
Electrical Power (Basic Machine) kVA 15
Basic machine Floor Plan (WxDxH) mm 2450 x 2950 x 2150
Machine Weight kg 4500
Air requirement CFM 4.5
Air Pressure bar 5

Application
